SYNKRO 3-row mounted stubble cultivators
3.00 to 5.00 m Working width
Description
You can use our SYNKRO three-gang stubble cultivators for shallow and deep tillage. A central adjustment system allows you to adjust the working depth quickly and easily.
Advantages
Perfect incorporation
Ultimate cultivation
Moving the whole surface, perfect incorporation and excellent quality tilth are what make SYNKRO stubble cultivators so popular with users. All our stubble cultivators are equipped with the field proven share geometries. These ensure uniform incorporation and intensive mixing of harvest residues, slurry, muck, mulch, etc. even in tough operating conditions. The mixing of residue from the harvest increases the fertility of the soil and protects from erosion.
Creating the best conditions
Because the wing shares overlap, the whole area of soil is cultivated thoroughly with both the deep and very shallow settings. For a working depth between 5 and 30 cm.
For shallow and deep cultivation
The points and wings ensure thorough mixing of the soil. Regardless of whether you intend to work very shallow or deep. Being able to adjust the height and angle of the wings ensures optimum soil penetration and mixing performance.
Compact frame
The compact frame is a trademark of mounted SYNKRO stubble cultivators. The first row of tines is very close to the tractor for a very favourable centre of gravity.
-
100 x 100 mm box section frame made from fine-grained steel gives the greatest stability.
-
The tapered frame design transfers the tractor's pulling power from the lower linkages right up to the rear roller mountings.
-
Thanks to the tapered frame the depth adjustment system is easily accessible on both sides without risk to the operator.
Adjustable headstock
Tractors with up to 190 hp have a huge range of hitch geometries. Reliable soil penetration performance and excellent working results are still achieved.
Mounting category on three-row mounted cultivators: Cat. II / 2.
SYNKRO 3030 / SYNKRO 3530
Two lower linkage mounting heights with clevis-type lower linkage mountings. The headstock angle can be adjusted and with three top linkage positions optimum adaptation to any tractor is guaranteed.
-
Headstock vertical = standard setting
-
Headstock angled forward for tractors with short top links
-
Headstock can be lowered for smaller tractors
SYNKRO 4030 K / SYNKRO 5030 K
On the folding models, the headstock provides three top link and two lower linkage mounting heights.
Mounting category on three-row, folding cultivators: Cat. III / 2, Cat. III / 3.
NOVA stone protection system
SYNKRO NOVA models are equipped with overload protection. PÖTTINGER has completely updated the NOVA stone protection system and it now features a newly-developed horizontal spring unit.
When obstacles are met at a depth of up to 30 cm, uninterrupted working is guaranteed by safe tripping and the large movement arc.
The triggering force of 550 kg diminishes as the leg is raised, therefore stones are not pulled up or loosened. This protects both the cultivator and the tractor.
On SYNKRO NOVA models the first row of tines is located as far forward as possible to bring the weight as close as possible to the tractor.
Two tine positions are possible for reliable soil penetration
Additionally, the tines are also protected by shear bolts
Proven components
- The levelling discs on SYNKRO NOVA models are also equipped with maintenance-free stone protection.
- Proven over many years in the field, the maintenance-free NONSTOP trip protection system features 40 mm-thick rubber elements.
- The sealed bearings are maintenance-free and do not need to be lubricated
- A labyrinth seal provides perfect protection for the bearing
- Levelling tines are also available as an option in lieu of the discs
