Telescopic wheel loaders
Ideal loaders for use in agriculture and construction
Inquiry
Description
If you are looking for a machine that is ideal for use on uneven terrain or in tight spaces with great stability and a high lift capacity then Schäffer telescopic loaders are among the most distinguished in their class. Not without reason as there are many important features such as the freely suspended rear axel or the protected hydraulic cylinder of the telescopic boom which are just a few of the reasons why these products have such an enviable reputation for long lasting performance.
You can chose between 12 models in the following range:
- power from 60 hp to 180 hp
- height of lifting 4.25 m to 6.90 m
- load capacity from 1 400 to 4 400 kg
Advantages
"EASY BRAKE" SYSTEM
The hydrostatic transmission is sufficient to reduce the speed in most situations. To actually stop use the multi-disc braking system EASY BRAKE, acting on all four wheels. The machine can stop safely and securely load any type of terrain, even inclined.
SCHAEFFER ARTICULATED JOINT
The joint between the front and rear of the loader provides maneuverability and stability. The mechanical connection of the hinge is of the floating type, which enables the four tires of the machine to be in contact with the ground even on rough terrains. No need of greasing it every day, as with other brands of machines of this class.
АXLES SCHAEFFER
The axles are the most critical components. Their purpose is to bear heavy loads and to make high hydrostatic force in torque to the wheels for many years of work. They are distinguished by tooth wheels and transmission of large sizes, differential or additional planetary wheel with high strength.
Multifunctional joystick
Through this joystick all operations are carried out smoothly and securely. Exceptional comfort at work due to the hydrostatic transmission with a joystick similar to motor control. Choosing the direction of travel, transport any type of cargo smoothly, accelerating speed without changing gear. The maximum speed reached is 15-20 km/h. Heavy loads can be moved both at high speed, and slowly and smoothly, by switching the fast and slow gears.
Technical parameters
|
Features
Models |
Engine |
Power (hp) |
Height of lifting (m) |
Height of unloading (m) |
Load capacity straight/bent (kg) |
Radius of turning (m) |
|
3550 T/3550 SLT |
Kubota, 4 cylinders with water cooling, Diesel |
50 |
3.85 |
2.95 |
1 700 |
1.23 |
|
3560 T/3560 SLT |
60 |
3.85 |
2.95 |
1 700 |
1.23 |
|
|
4560 T |
60 |
4.25 |
3.34 |
1 800 |
1.41 |
|
|
4580 T |
80 |
4.25 |
3.34 |
1 900 |
1.41 |
|
|
6370 T |
70 |
4.66/5.10* |
3.53 |
2 400 |
1.75 |
|
|
8090 T |
86 |
5.10 |
4.00 |
3 000 |
2.34 |
|
|
9630 T |
Deutz, 4 cylinders with water cooling, Diesel |
123 |
5.30 |
4.39 |
3 500 |
2.24 |
|
9530 T |
157 |
6.10 |
5.19 |
3 800 |
2.40 |
|
|
9380 T – 6 cyl. |
176 |
6.90 |
5.35 |
4 400 |
2.57 |
