Description
The Q series is a class of tractors apart, without equals on the market. The bold sloping design of the body, the reduced turning radius, the large and nearly isodiametric wheels of the four-wheel drive system and the powerful engine make the Q series the ideal machine for working among the rows of orchards and vineyards, with their limited clearance, height and manoeuvring space and generally steep and rugged terrain.
Advantages
- Maximum traction and grip thanks to its low centre of gravity
- Version with extra-low “low profile” cab starting from 180 cm
- Driving comfort: platform mounted on variable viscosity “silent-blocks”
- More versatile than an isodiametric tractor, offering better performance than a tracked model, excellent for on-road travel
- Perfectly balanced weight
Technical parameters
| Parameter | Value |
|---|---|
| Model | Goldoni Q80 |
| Type | Specialized tractor (orchards & vineyards) |
| Drive | 4WD (4x4) |
| Series | Q |
| Engine brand | HD Hyundai Infracore (Doosan) |
| Engine power | 56 kW / 75 HP |
| Fuel | Diesel |
| Number of cylinders | 4 |
| Displacement | 2400–2970 cm³ |
| Rated speed | 2300 rpm |
| Max torque | 310 Nm |
| Max torque speed | 1400 rpm |
| Emission standard | Stage V |
| After-treatment system | DOC + DPF |
| Transmission | Mechanical (up to 24F / 12R depending on configuration) |
| Maximum speed | 40 km/h |
| Length | approx. 3.2–3.4 m |
| Width | approx. 1.5–1.56 m |
| Height | approx. 2.1–2.3 m |
| Weight | approx. 2.3–2.4 t |
| Fuel tank capacity | up to 70 L |
| Rear tyres | 380/70 R20 |
| Front tyres | 280/70 R18 |
