FARO COMBILINE Combined rotor loader wagon
90 to 150 hp - 22 to 23 m³ volume
Inquiry
Description
With the FARO series, we meet your demand for high performance rotor technology for medium sized tractors. The rotor with dual tines is especially suitable for handling hay.
The basis for your success
High yield dairy cattle need a high quality basic ration with the optimum structure. This is readily consumed by the animals in sufficient quantities. That is the best way to prepare the rumen to process the forage as productively as possible. High base forage quality reduces dependence on concentrates and promotes animal health, both of which lower your costs.
Healthy cows will thank you with improved fertility levels and higher milk yields over a longer period of time. The bottom line is that you benefit from clean, high quality forage with higher profits from your dairy business.
Advantages
ROTOMATIC PLUS
1- ROTOMATIC PLUS
2 - Scrapers
3- Short chop system
4 - Knife protection system
- The loading rotor with a diameter of 750 mm achieves a high throughput during chopping, conveying and compacting. The 7 mm thick conveyor tines are made of durostat hardened and tempered boron steel and feed the crop perfectly into the chopping system.
- With a theoretical chopped length of 45 mm
- The reliable knife protection system protects the loader wagon from foreign objects, avoids downtimes and promotes a consistent chop length for the highest possible forage quality at high outputs.
- The large scraper area inside the loading chamber ensures excellent conservation for all types of forage. This makes the FARO highly suitable for mixed farming operations.
A controlled floating pick-up
FARO 4010 D COMBILINE
The sealed twin-race roller bearings fitted to the cam rollers are designed to withstand high stresses. With the sweeping action of the tines on the pick-up, it conserves the sward, lowers the level of dirt ingress and prevents unnecessary wear to the tines.
The pick-up with perfect ground tracking for the lowest possible crude ash content makes the loader wagon particularly suitable for harvesting forage.
Clean forage
The interaction of the controlled pick-up with the floating pick-up suspension and the low pressure on the ground results in the cleanest possible collection of the crop. This ensures the contamination level is within the limit values of 80-100 g / kg of dry matter.
Perfect forage flow
An optional wind guard with swath roller and guide plates ensure perfect forage flow with every type of crop, even at higher loading speeds.
Tidy transfer
The fully active tine leg length on the controlled pick-up transfers the flow of crop smoothly to the rotor, even in difficult harvest conditions.
Best chopping quality
Instead of dragging the forage through, the system promotes the best possible chopping quality.
The best chopping quality with a chopped length of 45 mm
The FARO is the ideal choice for high forage quality thanks to the chopping system with 31 knives and a theoretical chopped length of 45 mm.
The forage has the optimum structure for ruminants.
An optimum distance between the knives and tines ensures smooth operation and protects the knives from foreign objects.
Highest quality knives
The knives are produced from hardened tool steel and their pressed serrated edge ensures a precise chop. The extra-thick rear edge of the knife guarantees an extended service life.
Silage and harvest transport wagon combined
The FARO 4010 COMBILINE can also be used as a harvest transport wagon, turning it into a cost effective all-rounder.FARO 4010 D COMBILINE
1 - Straight tailgate flap or multifunction tailgate on D model
2 - Optional roof ropes with rear tarpaulin
3 -Tapered mudguards
4 - COMBILINE superstructure
- Power requirement: 90 to 150 PS
- Volume: 22 or 23 m³3
- Pick-up width: 1.85 m
Unloading
Straight tailgate flap
For full utilisation of the loading chamber.
D model with multifunction tailgate
The driveline to the beater rotors is concealed within the frame. The strong drive shaft is protected by a cam clutch at 1200 Nm.
Technical parameters
| Параметър | FARO 4010 L COMBILINE | FARO 4010 D COMBILINE |
|---|---|---|
| Loading volume (DIN 11741) | 23 m³ | 22 m³ |
| Theoretical chopped length | 45 mm | 45 mm |
| Number of knives max. | 31 pcs. | 31 pcs. |
| Pick-up recording width | 1,85 m | 1,85 m |
| Length | 8,41 m | 8,88 m |
| Width | 2,51 m | 2,51 m |
| Height | 3,35 m | 3,35 m |
| Height with ropes for roof | + 325 mm | + 325 mm |
| Number of scraper floor chains | 4 pcs. | 4 pcs. |
| Scraper floor motor (standard) | 1-speed | 1-speed |
| Scraper floor motor (option) | 2-speed | 2-speed |
| Length loading area (Width 2,1) | 5,68 m | 5,68 m |
| Loading volume with medium compression | 40 m³ | 40 m³ |
| Track width | 1,95 m | 1,95 m |
| Weight of basic version | 6350 kg | 6850 kg |
| Chassis | Tandem axle | Tandem axle |
| Permissible laden weight (standard) | 15000 kg | 15000 kg |
| Permissible laden weight max. | 18000 kg | 18000 kg |
| Tandem-axle, 25/40 kph | 15000 kg | 15000 kg |
| Tandem-axle, 30/40 kph* | 15000 kg | 15000 kg |
| Tandem-axle, 30/40 kph* max. | 18000 kg | 18000 kg |
